性能優越•安全性高•操作簡單•裝置方便 EXCELLENT. QUALITY. HIGH . SAFETY . SIMPLE OPERATION. CONVENIENT. INSTALLATION
|
|
特點：
1. 無噪音運轉安靜，夜間亦不破壞安寧
2. 鍋爐效率85%燃燒發揮最安全
3. 特殊爐體構造4~5分即有足壓蒸氣使用
4. 全自動電腦控制系統最完善。 自動給水•自動點火•自動熄火•操作簡單•安全性高•有保障
(1) OPERATE VERY QUITE, NO NOISE. CAN BE OPERATED AT NIGHT WITHOUT SPOIL THE
TRANQUILITY.
(2)MOST SAFE, THE BOILER INFLAMMATION RATIO CAN REACH TO 97% EFFICIENTLY. NO PUBLIC POLLUTION.
(3)SPECIAL BOILER BODY CONSTRUCTION, SURFFI- CIENT STEAM PRESSURE CAN BE GENERATED WITHIN 4-5 MINUTES.
(4)EQIPPFD WITH AUTOAMT[C COMPUTER SYSTEM.
WATER SUPPLY, INITIATION FIRE AND DEINITIA-TION ARE IN
AUTOMATION CONTROL. EASY TO OPERATE, HIGH SAFETY.
|
| 規格 Specification |
| 項目 ITEM | 型式 TYPE | ||||||
| EB-100E | EB-150E | EB-200E | EB-250E | EB-300E | |||
|
鍋爐馬力 HORSE POWER | BHP | 7 | 10 | 13 | 165 | 20 | |
|
相當蒸發量 EQUIVALENT EVAPORATION | KG/H | 100 | 150 | 200 | 250 | 300 | |
|
發熱量 CALORIFIC VALUE | Kcal/K(kw) | 53,900 | 80,850 | 107,800 | 134,750 | 161,700 | |
|
傳熱面積 HEATING SURFACE | m 2 | 2.7 | 3.0 | 3.78 | 4. 2 | 5. 4 | |
|
最高使用壓力 MAX. WORKING PRESSURE | Kgf/cm2(Mpa) | 10 | 10 | 10 | 10 | 10 | |
|
熱效率 EFFICIENCY | % | 87 | 87 | 87 | 87 | 87 | |
|
使用燃料 FUEL USED | 瓦斯 GAS | ||||||
|
燃量 消費量 FUEL CONSUMPTION VOLUME |
13A天然 13A NATURAL |
發熱量 8900KCAL/Nm 3 | 6. 9 | 10.3 | 13.8 | 17.2 | 20.7 |
|
LPG 桶式 LPG CYLINDRIC |
發熱量 12000Kcal/Kg | 5. 1 | 7.6 | 10.2 | 12.7 | 15.3 | |
|
本體設備電力 ELEC. OF MAIN EQUIPMENT | Kw | 1 | 1 | 1 | 1 | 1 | |
|
製品重量 WEG. OF PRODUCT | Kg | 380 | 410 | 520 | 550 | 750 | |
|
燃料入口管徑 DIA. OF FUEL,S INLET | 13A | mm | 20 | 20 | 25 | 32 | 32 |
| LPG | 20 | 20 | 20 | 20 | 25 | ||
|
給水入口管徑 DIA. OF WATERING INLET | 20 | 20 | 20 | 20 | 20 | ||
|
蒸氣取出口管徑 DIA. OF STEAM INLET & OUTLET | 20 | 20 | 25 | 25 | 25 | ||
|
罐水排水口管徑 DIA. OF WA-TERING AND DRAINAGE | 25 | 25 | 25 | 25 | 32 | ||
|
安全瓶吐出管徑 DIA. OF SAFE CYCLINDER,S OUTLET | 20 | 20 | 25 | 25 | 32 | ||
|
鍋爐尺寸 SIZE OF BOILER | 寬 WIDTH | mm | 700 | 700 | 800 | 800 | 900 |
| 長 LENGTH | mm | 1,050 | 1,050 | 1,150 | 1,050 | 1,320 | |
| 高 HIGH | mm | 1,600 | 1,700 | 1,760 | 1,860 | 2,050 | |
|
1.電源： 22OV, 38OV, 415V, 50-60 HE 皆可使用 2.本表所列規格尺寸僅供參考，因裝備之改良等原因得不經預告變更之。 3.表列瓦斯消費量係以低熱量﹝天然瓦斯：8900Kcal / Nm 3 桶式： 12000Kcal / Nm 3 ﹞， 鍋爐效率87%時，所附閥及概略重量以蒸氣壓力10Kg/cm2 時為準 1. POWER SOURCE: 22OV, 380V AND 50-6OHz ARE AVAILABLE. 2. SPECIFICATIONS LISTED ON THIS FORM ARE FOR REFERENCE ONLY, SPECIFICATIONS CHANGE BY IMPROVED EUIPMENT SHALL WITHOUT PRE-NOTIFICATION. 3. THE GAS CONSUMPTION VALUES LISTED ON FORM WERE BASED ON 87% BOILER EFFICIENCY WITH LOWER THERMO (NATURAL GAS: 890OKcal/Nm3, BARREL TYPE: 12000 Kcal/Nm3 ), AND THE STEAM PRESSURE OF IOKg/cM2 APPROXIMATELY. |
